NP60N055KUG
TYPICAL CHARACTERISTICS (T A = 25°C)
120
100
80
60
40
20
0
DERATING FACTOR OF FORWARD BIAS
SAFE OPERATING AREA
100
90
80
70
60
50
40
30
20
10
0
TOTAL POWER DISSIPATION vs.
CASE TEMPERATURE
0
25
50
75
100
125
150
175
0
25
50
75
100
125
150
175
1000
T C - Case Temperature - ° C
FORWARD BIAS SAFE OPERATING AREA
T C - Case Temperature - ° C
R DS(on) Limited
I D(pulse) = 240 A
100
10
(at V GS = 10 V)
I D(DC) = 60 A
PW = 100 μ s
1 ms
DC
1
0.1
T C = 25°C
Single pulse
10 ms
0.1
1
10
100
V DS - Drain to Source Voltage - V
TRANSIENT THERMAL RESISTANCE vs. PULSE WIDTH
100
R th(ch-A) = 83.3°C/W
10
1
R th(ch-C) = 1.70°C/W
0.1
Single pulse
0.01
100 μ
1m
10 m
100 m
1
10
100
1000
PW - Pulse Width - s
Data Sheet D16862EJ1V0DS
3
